Draughtsman Mechanical

Draughtsman Mechanical deals with the study of machinery and mechanical tools. In this program, you will learn about types of machines, designing of machines, software for machines design, freehand sketching, equipment used in making machines, use of AutoCAD, and many more. Basically, mechanical draughtsman is a basic-level course in the field of machines and machine drawing.

Professional Knowledge

· Soft Skills: Its importance and Job area after completing training.

· Nomenclature

· B.I.S. Lines

· Type of lettering proportion

· Polygons and Circles

· Terminology

· Dimensioning

· Projections

· Importance of freehand sketching

· Constructions of different types of scales

· Definition of development

· Principle of isometric projection

· Types of perspective projection

· Screw Threads, Types, Uses

· Types of Nuts

· Different types of foundation bolts

· Types of assembly drawing

· Types of fastening materials

· A.C & D.C motors generators

· Couplings

· Bearing, Types, Uses

· Introduction to computer

· Introduction to Auto CAD, Advantages

· Introduction to 3D

· Creating templates

· Dimensioning drawings

· Modifying styles in dimensioning

· Belts power

· Piping materials

· Transmission of power

· Use of cams in Industry

· Brief description of petrol, diesel and gas engines

· Working principle of valves and their description

· Working principle and function of hydraulic jack

· Structural Steel B.I.S.

· Lay out of Machines Foundations

· Function of Gauges

· Introduction to solid works

· Drawings and Detailing

Professional Skills

· Importance of Trade Training

· Health and Safety

· Importance of Housekeeping & Good Shop Floor Practices

· Practice using instruments

· Types of Lines and Their uses

· Block letters and numerals

· Ellipse, parabola, and hyperbola

· Dimensioning technique

· Projection of Solids

· Freehand sketching

· Isometric projection of geometrical solids

· Freehand sketching

· Types of nuts, washers, bolts, studs

· Working drawing of welded structures

· Types of rivets

· Allied Trade – Fitting, Turning, Machinist, Sheet Metal, Electrician, etc

· Grades and Micron values

· Working Drawing of a simple bearing

· Practice on Computer

· Introduction to Auto CAD

· Introduction to 3D

· Creating templates

· Dimensioning drawings

· Modifying styles in dimensioning

· Belts power

· Piping materials

· Transmission of power

· Use of cams in Industry

· Brief description of petrol, diesel and gas engines

· Safety Valve

· Structural Steel Roof Truss Joints

· Drawing of a Drilling Jig

· Different Types of Gauges

· Sketching of a Press Tool

· Sketching & Assembly

· Exercise Using Copy & Paste

· Exercise on Screw Jack

Draughtsman Mechanical Jobs

The job opportunities for draughtsman mechanical is good in the market.The higher probability is that you get a job in any factory or power plant. In India, Industrialization is growing day by day. As a result, it creates a lot of new employment opportunities for people. The future scope and demand for these types of professions are high. Some of the job profiles are as follows:

· Machine Designer

· Component Designer

· Architectural Assistant

· Technical Assistant

· Structural Draughtsman

· AutoCAD Expert

· Draughtsman Piping
